1. Inner tank: made of stainless steel SUS3042B/SUUS316,1.2mm/1.5mm
2. Outer tank: made of colored steel(colored can be chosen by the client)
3. Insulation: polyurethane, 50mm thickness. Heat preversation for 72 hours.
4. Stand: flat roof or slope roof. can be designed combined with the house, wind resistant.
5. flat panel: beautiful in design, high tempered glass.
| Model |
SKI-2.0-80 |
| Collector Dimension(mm) |
2000 x 1000 x 80 |
| Overall area(m2) |
2.0 |
| Aperature area(m2) |
1.84 |
| Absorber area(m2) |
1.84 |
| Fluid capacity |
1.8L |
| Header dimension(mm) |
Φ22 |
| Welding way |
Laser welding |
| Max working pressure |
0.6mpa |
| Absorber material |
Aluminium/Full plate |
| Absorber coating |
Blue selective coating |
| Absorption |
95% |
| Emittance |
5% |
| Insulation material |
Fibre glass |
| Insulation thickness(mm) |
back:30 |
| Transmittance |
92% |
| Glazing material |
low iron tempered textured glass 3.2mm
|
|
Frame
|
Aluminium alloy |
| Back plate |
Aluzinc steel |
| Frame color |
Silver/Black/Brown |
| Sealing |
Seilicon glue |
| Net weight(kg) |
31 |
| Model |
PSF-100L |
PSEF-150L |
PSF-200L |
PSF-300L |
|
Flat Panel
1000 x 2000 x 80mm
|
One pcs
|
One pcs
|
Two pcs
|
Two pcs
|
| Absorbing Area |
2m2 |
2m2 |
4m2 |
4m2 |
| Inner tank dimension |
380mm |
440mm |
440mm |
440mm |
| Outer tank dimension |
480mm |
540mm |
540mm |
540mm |
| Tank length |
1060mm |
1200mm |
1550mm |
2200mm |
| Packing size (Tank) |
1160 x 480 x 480mm |
1300 x 590 x 560mm |
1650 x 590 x 560mm |
2300 x 590 x 560mm |
| 20ft container |
52 sets |
40 sets |
27 sets |
23 sets |
| 40HQ container |
126 sets |
97 sets |
66 sets |
55 sets |
|
